Kenwood introduced the TS-2000 in 2000 and built it until 2018. It puts HF, 6 m, 2 m and 70 cm in one 7.8 kg box at 100 W, or 50 W on 70 cm, and the TS-2000X adds 23 cm at 10 W. The main receiver uses IF DSP, so you set the bandwidth in software with no filters to buy. A second, independent receiver for 2 m and 70 cm runs alongside it, and there's a one-touch satellite mode. It also has an automatic tuner for HF and 6 m, a built-in TNC for packet and DX cluster spots, and Sky Command II on the US model for remote control from a Kenwood handheld. The TS-B2000 is the same radio as a black box with no front panel. Kenwood's last firmware, 1.12, came out in 2015.
TS-2000 (HF to 70 cm)TS-2000X (adds 23 cm)TS-B2000 (black box run from a computer or the RC-2000 head)TS-2000LE (black limited edition for Kenwood's 60th anniversary)
160 m to 6 m incl. WARC, 2 m, 70 cm; 23 cm on the TS-2000X or with the UT-20
Modes
SSB, CW, AM, FM, FSK
Power out
100 W HF, 6 m and 2 m; 50 W on 70 cm; 10 W on 23 cm
Receivers
Main receiver with IF DSP, plus a sub receiver for 2 m and 70 cm (FM and AM)
Power supply
13.8 V DC, 20.5 A on transmit
Weight
7.8 kg
Finals
2SC5125 pair (HF/6 m), 2SC2694 pair (2 m), 2SC3102 (70 cm)
Also listed as
TS2000, TS-2000X, TS2000X, TS-B2000
Typical eBay ask (Oct 15, 2026)
$1,100–$2,075
Bench check
Power, receive, finals and supply
Transmit power
Kenwood rates it at 100 W on HF, 6 m and 2 m, 50 W on 70 cm, and 10 W on 23 cm with the UT-20 or on the X. Ask for a wattmeter reading into a dummy load on HF, 6 m, 2 m and 70 cm. Each band group has its own final stage, so one good band doesn't prove the rest.
Receiver
The main receiver covers 30 kHz to 60 MHz plus 2 m and 70 cm, and a separate sub receiver handles 2 m and 70 cm on FM and AM. Ask whether the main receiver hears signals on every HF band, 6 m, 2 m and 70 cm, and whether the sub receiver works too. Owner repair notes on mods.dk include a front end killed by overload from another transmitter, so a deaf band matters.
Finals
Kenwood's service manual lists a pair of 2SC5125s for HF and 6 m, a pair of 2SC2694s for 2 m and a 2SC3102 for 70 cm, with 2SC1972 drivers. The manual warns that transmitting without an antenna or matched load may damage it. Owner notes on mods.dk cover a pre-driver overheating fix and fake 2SC1972 replacements, so ask what's been replaced.
Power supply
It runs on 13.8 V DC through a 6-pin Molex lead, drawing up to 20.5 A on transmit. Kenwood's matching supply was the PS-53 (22.5 A). Check the supplied DC cable is in the photos.
Dial and display
Owner repair notes on mods.dk cover PLL lock faults on the TS-2000X, a display that loses power, display bulbs swapped for LEDs and a worn multi-channel encoder. Ask for a photo with the display lit on 2 m and 70 cm, and whether the knobs tune without skipping.
Filters and options
Filtering is done in the DSP, so there are no crystal filters to buy. The automatic tuner covers HF and 6 m only, and a 1200/9600 bps TNC is built in. The options that change a listing are the UT-20 23 cm unit (standard on the X), the DRU-3A recording unit, the VS-3 voice unit and the RC-2000 remote head.
Should come with it
Hand microphone
DC power cable
Instruction manual
UT-20 23 cm unit (standard on the TS-2000X)
Check the listing photos against this list, and ask the seller about anything you can’t see. A missing piece should come off the price.
What to check
Owner repair notes on mods.dk cover a front end killed by overload from another transmitter, PLL lock faults on the X, pre-driver overheating and fake 2SC1972 replacement drivers. Kenwood warns that transmitting without an antenna or matched load may damage it.
01Power out: Ask for a wattmeter reading into a dummy load on HF, 6 m, 2 m and 70 cm. You want about 100 W on the first three and 50 W on 70 cm.
02Receive on every band: Ask whether the main receiver hears signals on every HF band, 6 m, 2 m and 70 cm. Every band should sound alive, since overload from another transmitter can kill the front end.
03Sub receiver: Ask the seller to show the sub receiver hearing a 2 m or 70 cm signal. It should work alongside the main receiver.
04Display and knobs: Ask for a photo with the display lit, and whether the knobs skip when tuning. A bright, even display and smooth tuning are what you want.
05Repairs: Ask what's been replaced, especially the drivers or PA. Genuine 2SC1972 drivers matter, since fakes have turned up in repairs.
0623 cm: Check the label for TS-2000X, or ask whether a UT-20 is fitted. Either way there should be an extra N jack on the back for 23 cm.
07Supply and mic: Check the photos for the hand mic, DC cable and manual. You'll need a 13.8 V supply good for 20.5 A, such as Kenwood's PS-53.
08MARS mod: If the title says MARS or CAP mod, it was changed to transmit outside the ham bands. That's only for authorized MARS or CAP stations, so ask what was changed.
09Firmware: Ask which firmware it runs. Kenwood's last update, 1.12, fixed extra dots and dashes from the keyer with a single-lever paddle.
We'd buy quantumheat100's TS-2000 at $1,000 with free shipping, the cheapest here, since its photo shows it switched on with the display lit, though the title makes no test claim. There are at least 10 for sale, most asking $1,100 to $2,075 delivered (median about $1,421), and the two titled working or tested ask $2,091 and $2,300. Each band group has its own final stage, so ask for a wattmeter reading into a dummy load on HF, 6 m, 2 m and 70 cm, and for the sub receiver hearing a 2 m signal. None is titled with a supply, so budget for a 13.8 V supply good for 20.5 A, like Kenwood's PS-53. Two accounts share one title at $1,325 and $1,750, so ask both for a photo of the serial label.
Listed now
10
For parts
0
Typical ask
$1,100–$2,075
Full range
$950–$2,250
★Cheapest
$999.95delivered
The lowest delivered TS-2000 at $1,000 with free shipping, and the photo shows it on with the display lit. There's no test claim and no mic titled, so ask for power out on HF, 6 m, 2 m and 70 cm before you pay.
Delivered prices include shipping as eBay quoted it to a US address on Oct 15, 2026. Many sellers charge by distance, so your total may differ. eBay shows yours before you pay.
